Nominal Carrying Caapacity: 80 Ton
Tongs Clamping Moment: 1,600 kNm
Tongs Opening Without Insert: 800 - 2000mm
Tongs Opening With Insert: 200 - 800mm
Tongs Open with Extension Arms: 100 - 2800mm
Tongs Centre Height Above Rails: 1700 - 4500mm
Vertical Stroke of Tongs: 2800mm
Vertical Tilting Angle of Tongs: Upto 15 degrees
Distance Between Rails: 5000mm
Max. Turning Diameter: 3900mm
Speed Forging: 30m/min
Speed Travelling: 50m/min
Total Installed Power: 495 kW
